GF-1 B/C/D Satellite Imagery

Launched in March 2018, the GF-1 B/C/D satellites form a powerful constellation that enhances global remote sensing capabilities. Working in conjunction with GF-1A, this series provides a reliable stream of 2m panchromatic and 8m multispectral imagery, offering a perfect balance of detail and coverage for large-scale monitoring projects.

GET A QUOTE CHAT ON WHATSAPP
Artistic representation of the GF-1 satellite constellation in orbit.

Resolution

2m Pan

Revisits

1-4 Days

Swath Width

66 km

Accuracy

50m CE90

Bands

5

Mission Life

5-8 Years

Technical Specifications

Launch DateMarch 31, 2018
Altitude645 km
Orbit TypeSun-Synchronous
Mission Lifetime5-8 years
Panchromatic Resolution2m
Multispectral Resolution8m (PMC), 16m (WFI on GF-1A)
Swath Width66 km (PMC), 830 km (WFI on GF-1A)
Revisit Capacity~1 day (Constellation), 4 days (Single)
Geolocation Accuracy50m CE90 (GF-1A)
Spectral Bands (PMC) Pan: 0.50-0.80μm
Blue: 0.45-0.52μm
Green: 0.52-0.59μm
Red: 0.63-0.69μm
NIR: 0.77-0.89μm

Features and Benefits

  • High Revisit Frequency: With the full constellation, achieve a revisit capacity of approximately 1 day, ensuring you never miss critical changes on the ground.
  • Balanced Resolution: The 2m panchromatic and 8m multispectral resolution is a cost-effective choice for detailed mapping over moderately sized areas.
  • Wide-Area Awareness: Combined with GF-1A's 830km wide-swath imager, the constellation provides excellent regional coverage and situational awareness.
  • Proven Multispectral Analysis: Standard Red, Green, Blue, and Near-Infrared (NIR) bands are essential for vegetation health monitoring (NDVI), land use classification, and environmental studies.

Applications

Agriculture: Monitor crop health across large regions, assess irrigation needs, and support precision agriculture strategies with frequent multispectral imagery.
Environmental Monitoring: Track land use changes, monitor water quality in lakes and rivers, and assess the impact of environmental shifts over time.
Urban & Regional Planning: Use as a reliable source for creating and updating base maps, analyzing urban growth patterns, and monitoring infrastructure projects.
Disaster Management: Contribute to damage assessment, response planning, and recovery monitoring for large-scale natural disasters.

Why Choose XRTech Group for GF-1 Imagery?

We provide more than just satellite data; we deliver comprehensive solutions tailored to your project's specific needs, ensuring you get actionable insights quickly and efficiently.

Expert Consultation

Our geospatial experts provide a free consultation to understand your needs and recommend the best acquisition parameters to ensure optimal results for your project.

Rapid Delivery

Leveraging our direct partnership and access to a vast 130+ satellite constellation, we offer fast turnaround times, delivering imagery in days, not weeks.

Seamless Integration

We deliver data in industry-standard formats (like GeoTIFF) compatible with your GIS, CAD, or modeling software, with a team ready to support your workflow.

GF-1 Series Sample Imagery

Sample 2m panchromatic satellite imagery from the GF-1 constellation.
Example of 8m multispectral satellite data from the GF-1 series.
