ZY-1 02C Satellite Imagery

The ZY-1 02C satellite is a versatile Earth observation platform equipped with high-resolution panchromatic and multispectral cameras. It provides detailed imagery suitable for a wide range of geospatial applications, including land management, urban planning, and environmental monitoring, offering a strong balance of detail and coverage.

GET A QUOTE CHAT ON WHATSAPP
Artistic representation of the ZY-1 02C satellite in orbit.

Max Resolution

2.36m Pan

MS Resolution

10m

Max Swath

60 km

Sensor

Optical

Bands

Pan + 3 MS

Technical Specifications

Attribute High-Resolution Camera 5mPAN/10mMS Camera
Resolution2.36m (Pan)5m (Pan), 10m (MS)
Swath Width27 km (1 camera) / 54 km (2 cameras)60 km
Spectral BandsPan: 0.50-0.80μm Pan: 0.51-0.85μm
Green: 0.52-0.59μm
Red: 0.63-0.69μm
NIR: 0.77-0.89μm
Max Off-Nadir Angle±25°N/A

Features and Benefits

  • High-Resolution Detail: The 2.36m panchromatic camera provides sharp, detailed imagery ideal for precise feature identification and base mapping.
  • Flexible Resolution Options: With resolutions from 2.36m to 10m, ZY-1 02C offers flexibility for different levels of detail, from intricate mapping to broader area analysis.
  • Valuable Multispectral Data: The inclusion of Green, Red, and Near-Infrared bands is crucial for vegetation health analysis (NDVI), land classification, and environmental studies.
  • Balanced Coverage: Swath widths of up to 60 km provide a good balance between the level of detail captured and the area covered in a single pass.

Applications

Urban Planning & Development: Create detailed base maps, monitor urban expansion, and analyze infrastructure projects with high-resolution imagery.
Land Use & Land Cover Mapping: Accurately classify different land types and track changes over time using the combination of panchromatic and multispectral data.
Resource Management: Support comprehensive surveys of natural resources, including agricultural areas, forests, and water bodies.
Environmental & Ecological Studies: Assess vegetation health, track the impact of deforestation, and conduct general ecological assessments.

Why Choose XRTech Group for ZY-1 02C Imagery?

We provide more than just satellite data; we deliver comprehensive solutions tailored to your project's specific needs, ensuring you get actionable insights quickly and efficiently.

Expert Consultation

Our geospatial experts provide a free consultation to understand your needs and recommend the best acquisition parameters to ensure optimal results for your project.

Rapid Delivery

Leveraging our direct partnership and access to a vast 130+ satellite constellation, we offer fast turnaround times, delivering imagery in days, not weeks.

Seamless Integration

We deliver data in industry-standard formats (like GeoTIFF) compatible with your GIS, CAD, or modeling software, with a team ready to support your workflow.

ZY-1 02C Sample Imagery

Sample 2.36m high-resolution imagery from the ZY-1 02C satellite.
Example of 10m multispectral satellite data from ZY-1 02C used for vegetation analysis.
